Rolls VB12-200LFP 12V 200Ah LiFePO₄ Battery

Key benefits

  • High-capacity 12V 200Ah LiFePO₄ battery in a standard BCI case, ideal as a drop‑in upgrade for deep‑cycle lead‑acid in leisure, marine and off‑grid systems.
  • Long service life with >6000 cycles at 80% depth of discharge and >3000 cycles at 100% DOD, significantly reducing replacement frequency.
  • Integrated hardware BMS with full protection plus Bluetooth connectivity and dedicated iOS/Android app for easy monitoring.

Brief description

The Rolls VB12-200LFP 12V 200Ah LiFePO₄ Battery (R12‑200LFP) is part of the Rolls R‑Series LFP range, using cylindrical LiFePO₄ cells in a rugged ABS enclosure. With 2.56kWh of energy, high continuous discharge current and fast-charging behaviour, it suits motorhomes, caravans, boats, commercial service vehicles and small off‑grid systems where dependable 12V storage is required. An integrated 4S200A BMS manages safety functions, while Bluetooth and the Rolls app provide clear state-of-charge and status information.

Key features

  • 12.8V nominal, 200Ah capacity and 2.56kWh total energy for larger 12V leisure and off‑grid banks.
  • Standard-size BCI ABS container with rope/plastic handles and M8 terminals for straightforward VRLA replacement.
  • Fast charge/discharge performance with up to 100A charge, 200A continuous discharge and 800A surge (300ms).
  • Wide operating temperature range and IP65 enclosure for demanding mobile and outdoor environments.
  • Configurable up to 4 units in series and 4 in parallel (4S4P at 48V) or up to 6 in parallel at 12V.

Technical specifications

General

Series R‑SERIES LFP
Warranty See Warranty Terms
Volts 12
Design SPEC
Terminal Type M8
Included Hardware M8 stainless bolts & washers

Charge / Discharge

Charge Voltage Range 14.0 - 14.6V
Recommended End of Discharge Voltage 12.0 V
End of Discharge Protection Voltage 10.0 V
Recommended Charge Voltage 14.4 V
Recommended Charge Current 0~10°C (32‑50°F) 0.2C 40A
Recommended Charge Current 10~35°C (50‑95°F) 0.5C 100A
Recommended Charge Current 35~50°C (95‑122°F) 0.2C 40A
Charge Mode Charge at recommend voltage & current by temperature until charge current drops to ≤ 0.05C (CC,CV)
Charge Mode Notes DO NOT USE TEMPERATURE COMPENSATION; No BTS (Battery Temperature Sensor)
Max Continuous Charge Current 100 A
Max Continuous Discharge Current 200 A
Surge Current Limit 800 A (300ms)
Charge Temperature Range 0°C~55°C (32~131°F)
Discharge Temperature Range -20°~60°C (-4~140°F)
Storage Temperature Range -5°~45°C (23~113°F)

Capacity

Nominal Capacity 200 AH
Total Energy 2.56 kWh
Nominal Voltage 12.8 V

Safety

Cell type Cylindrical LiFePO4 cells [ITR26-70/40E 4Ah, 26700] (UL1642)
Standards IEC62133 (cell), IEC62619(cell), UN38.3 (cell/pack)
Certifications ROHS (cell), CE system certification, IP65 Rating

Design

Container ABS
Cover ABS
Handles Rope / Plastic Handle
Design features Standard-size (BCI) ABS container for easy VRLA replacement; Fast charge/discharge performance; Maintenance-free operation; Bluetooth Connectivity & dedicated IOS & Android App

Battery Management System (BMS)

Type Integrated hardware BMS inside
Internal BMS Model 4S200A
Protection topology Independent charge & discharge protection
Protection functions Short-Circuit Protection, Over-Voltage Protection, Low-Voltage Protection, Over-Current Protection, Low-Temperature Protection, Over-Temperature Protection

12V LFP profile – mechanical

Weight 22 kg / 48.5 lbs
Length 490 mm / 19.3"
Width 171 mm / 6.73"
Height 240 mm / 9.45"
Height Incl. Term. 243 mm / 9.57"
Measurement note Product measurements & weights are calculated based on sample data. Individual specifications are subject to vary due to the manufacturing process & battery components.

Operational limits and configuration

Expected Cycle Life >6000 @ 80% DOD, >3000 @ 100% DOD
Series Connection 4 UNITS MAX (48V)
Parallel Connection 4 UNITS MAX (48V) or 6 UNITS MAX (12V)
Connectivity Up to 4S4P (in 48V configuration) or 1S6P (in 12V configuration)
Revision Rev.#2 | February 2024

Shipping

Shipping is available to the UK, Ireland, Africa, the Caribbean and worldwide. If the shipping rate is not shown at checkout, please contact us on +44 2080640335 or info@energian.co.uk for a tailored shipping quote.

UK expert support

UK expert support is available to help with battery selection, sizing and configuration of the Rolls VB12-200LFP 12V 200Ah LiFePO₄ Battery in leisure, marine and off‑grid systems. For larger banks or systems with inverters, chargers and DC distribution we recommend installation and commissioning via our trusted partners to ensure safe operation and correct protection settings.

You can contact us by phone, email or live chat, or visit our office for an in‑person consultation to discuss your project and preferred system layout.
