24% off

Rolls VB12-100LFP 12V 100Ah LiFePO4 Battery


By Rolls Battery
Minus Plus

Delivery available

More details Right

Rolls VB12-100LFP 12V 100Ah LiFePO₄ Battery

Key benefits

  • 12V 100Ah LiFePO₄ battery in a standard BCI Group 24 case, ideal as a drop‑in replacement for many VRLA batteries in off‑grid, backup and mobile systems.
  • Long service life with an expected 6000 cycles at 80% depth of discharge, helping to reduce replacement and maintenance costs over time.
  • Integrated hardware BMS with multiple protection functions plus Bluetooth connectivity and dedicated iOS/Android app for easy monitoring.

Brief description

The Rolls VB12-100LFP 12V 100Ah LiFePO₄ Battery is part of the Rolls VB Series LFP range and is designed as a robust, maintenance‑free alternative to traditional 12V lead‑acid batteries. With a nominal energy of 1.28kWh, up to 6000 cycles at 80% DOD and an IP65‑rated ABS enclosure, it suits small commercial backup systems, telecoms, remote monitoring, mobile power and off‑grid applications. Integrated BMS and Bluetooth connectivity simplify protection, status checks and fleet management in multi‑battery systems.

Key features

  • 12.8V nominal, 100Ah rated capacity and 1.28kWh total energy in a compact Group 24 footprint.
  • Standard‑size BCI ABS container with integrated top‑mount handles for straightforward VRLA replacement and handling.
  • Heating for low‑temperature operation and wide charge/discharge temperature range from -20°C to +55°C.
  • Integrated BMS with independent charge and discharge protection, including over‑voltage, low‑voltage, over‑current, short‑circuit and temperature protections.
  • Up to 4 in series and 4 in parallel (4S4P at 48V) for modular system building in DC storage banks.

Technical specifications

General

Series VB Series LFP
Warranty See Warranty Terms
Volts 12
Design Grp 24
Terminal Type M8
Included Hardware M8 stainless bolts & washers
Container ABS
Cover ABS
Handles Integrated Top Mount
Internal BMS Model RD-RJ4S100A
Connectivity Up to 4S4P (in 48V configuration)
Rev. Rev.#2 | November 2025

Charge / Discharge

Charge Voltage Range 14.2–14.6V
End of Discharge Protection Voltage 11.2 V
Recommended Charge Current (‑20~10°C / ‑4–50°F) 0.5C 50A
Charge Mode Charge at recommend voltage & current by temperature until charge current drops to ≤ 0.05C (CC,CV)
Charge Mode Notes DO NOT USE TEMPERATURE COMPENSATION; No BTS (Battery Temperature Sensor)
Max Continuous Charge Current 100 A
Max Continuous Discharge Current 100 A
Charge Temperature Range -20~55°C (-4~131°F)
Discharge Temperature Range -20~55°C (-4~131°F)
Storage Temperature Range -20~55°C (-4~131°F)

Capacity

Nominal Capacity 100 AH
Total Energy 1.28 kWh
Nominal Voltage 12.8 V

Safety

Cell type Prismatic LiFePO₄ cells [CB79/3.2V100Ah]
Standards IEC62619(cell), UL 1973 (cell), UN38.3 (cell/pack)
Certifications ROHS (cell), CE system certification, IP65 Rating

Design

Container format Standard-size (BCI) ABS container for easy VRLA replacement
Performance Fast charge/discharge performance
Operation Maintenance-free operation
Low temperature feature Heating for low temperature operation
Connectivity feature Bluetooth Connectivity & dedicated IOS & Android App

Battery Management System (BMS)

Type Integrated hardware BMS inside
Protection topology Independent charge & discharge protection
Protection functions Short-Circuit Protection, Over-Voltage Protection, Low-Voltage Protection, Over-Current Protection, Low-Temperature Protection, Over-Temperature Protection

Mechanical specifications

Weight 10 kg / 22 lbs
Length 260 mm / 10.24"
Width 168 mm / 6.61"
Height 210 mm / 8.27"
Height incl. terminals 215 mm / 8.46"
Measurement note Product measurements & weights are calculated based on sample data. Individual specifications are subject to vary due to the manufacturing process & battery components.

Operational limits and configuration

Expected Cycle Life 6000 @ 80% DOD
Series Connection 4 UNITS MAX (48V)
Parallel Connection 4 UNITS MAX

Shipping

Shipping is available to the UK, Ireland, Africa, the Caribbean and worldwide. If the shipping rate is not shown at checkout, please contact us on +44 2080640335 or info@energian.co.uk for a tailored shipping quote.

UK expert support

UK expert support is available to help with battery selection, sizing and configuration of the Rolls VB12-100LFP 12V 100Ah LiFePO₄ Battery in off‑grid, backup and mobile power systems. For larger multi‑battery banks or systems with inverters and chargers we recommend installation and commissioning through our trusted partners to ensure safe operation and correct protection settings.

You can contact us by phone, email or live chat, or visit our office for an in‑person consultation to discuss your application and preferred system layout.

Documents available for download
