Empower Your Energy: Solinteg MHS-6K-30A 6kW High Voltage Hybrid Inverter
The MHS-6K-30A is a single phase, hybrid, high voltage inverter with compact size and stylish appearance, Ideal for home use. It offers optimum power and storage, powerful load & backup coverage and features an OLED display and App for setup and data management. With plug and play, IP65 and silent operation. 10 years working warranty.
The Solinteg MHS-6K-30A boasts straightforward installation, saving you precious time on-site. With the OLED/App monitoring and control become effortlessly convenient, simplifying support from afar.
- IP65 rated - ideal for outdoor installations.
- 160% DC oversizing, 80V start-up voltage, and continuous 110% AC overloading, high round-trip efficiency of 97.6%
- Integrated OLED display and mobile app for efficient system monitoring and management.
- Five work modes, six charge/discharge intervals, and centralised smart management
- Efficient radiators that maintain optimal operating temperature, extending the life of the inverter.
- Seamlessly integrates with Pylontech Force H2 and Force H3 high voltage batteries, providing flexibility for various setups.
Fast Delivery Across the UK
Experience the benefits of the Solinteg 6kW single phase hybrid HV inverter with quick 2-3 working days delivery within the UK (longer to the Highlands, islands, and Northern Ireland).
BATTERY | |
Battery type: | Lithium Battery (with BMS) |
Battery voltage range: | 80-450V |
Max. charge current: | 30A/30A |
INPUT PV | |
Max. Recommended Input PV: | 9,600W |
Start-up voltage: | 80V |
Max. PV input voltage: | 600V* |
Rated PV input voltage: | 360V |
MPPT voltage range: | 100-550V* |
Max. Input Current: | 15A/15A |
Max. Short Circuit Current: | 20A/20A |
No. of MPP Trackers | 2 |
No. of strings per MPP Tracker: | 1/1 |
OUTPUT AC | |
Nominal AC Power: | 6000W |
Max. Apparent AC power: | 6600VA |
Max. AC Current: | 28.7A |
Rated AC voltage: | LIN/PE; 220/230/240V |
Rated AC frequency: | 50/60Hz |
Power factor: | 0.8 leading ... 0.8 lagging |
Max. total harmonic distortion: | <3% @Rated output power |
INPUT AC | |
Max AC Power: | 10,000VA |
Max. charging power of battery: | 6000W |
EPS OUTPUT (WITH BATTERY) | |
Max. EPS Power: | 6000W |
Max. output apparent power: | 6600VA |
Max. EPS Current: | 28.7A |
UPS switch time: | <10ms |
Rated AC voltage: | LIN/PE; 220/230/240V |
Rated AC frequency: | 50/60Hz |
Max. harmonic distortion: | <3% @Linear load |
EFFICIENCY | |
Max. efficiency: | 97.6% |
Euro efficiency: | 97.0% |
GENERAL | |
Ingress protection: | IP65 |
Dimensions [WxHxD]: | 534x478x210mm |
Weight: | 27kg |
Operating Temperature Range: | -30°C~+60°C |
Humidity: | 0-100% |
Communication: | CAN, RS485, WiFi/LAN (Optional) |
** Max apparent power from the grid means the maximum power imported from the utility grid used to satisfy the backup loads and charge the battery;
1) G98: 3.68kVA; 2) G98: 1600A; 3) AS 4777.2: 5.0kW, VDE-AR-N 4105: 4.6kW; 4) AS 4777.2: 5.0kVA, VDE-AR-N 4105: 4.60kVA, C10/11: 5.0kVA;
5) AS 4777.2: 21.7A, VDE-AR-N 4105: 21.0A, C10/11 217A;
