SL Rack Fast Flat Solar Panel Mounting System for Flat Roofs

The SL Rack Fast Flat solar panel mounting system is an aerodynamic, time-saving and durable racking solution engineered specifically for residential, commercial, and industrial flat roofs. Its unique engineering focuses on reducing labor time, freight costs and structural wear.

Key Features

Tool-Less Click Technology: Racks and connectors snap together using an innovative click system that requires zero tools for basic structure assembly.

Time Savings: Reduces on-roof installation time by up to 50% compared to traditional rail configurations.

Pre-Assembled Delivery: Shipped 100% pre-assembled so installers only need a single Torx 40 tool to lock down the solar module

Freight Efficiency: Up to 200 interlocking pieces (providing roughly 100 kW of solar capacity) fit onto a single Euro pallet, slashing shipping expenses by up to 50%
Low Bearing Pressure: Employs large 200x200 mm base plates that distribute weight evenly, making it perfectly optimised for soft-insulated roofs.
EPDM Base Mats: Integrated high-friction EPDM mats protect the sensitive outer roof lining from friction damage without needing physical roof penetrations.
Screw-Free Wind Deflectors: Snap-on Fast Flat Wind Deflectors secure tightly using universal clamps rather than sharp self-tapping screws.
Minimised Ballast Weight: The advanced aerodynamic design drastically reduces wind uplift, lowering the amount of heavy concrete ballast required on the roof.
Flexible Ballast Options: Compatible with different sizes and weights of individual ballast tiles

    Where to use

    This kit is designed for roof-mounted solar installations on commercial, industrial or residential buildings. Typical applications include warehouse, logistics, and office buildings and public-sector premises seeking an integrated, low-profile solar installation.

    Flat mounting introduces structural, weather-proofing and roof-fixing considerations that vary by building type and roof material. This system should be installed by a qualified solar installer or one of Energian's trusted installation partners, who can assess wall suitability, fixings and local wind/snow load requirements before installation.

    Technical specifications

    Product name SL-Rack Fast Flat Solar Panel Mounting Kit
    System type Flat roof solar panel mounting system
    Panel orientation South / East-West
    Panel placement Landscape
    Panel capacity Unlimited
    Installation method Tool-free, snap-into-place click mechanism
    Compatible wall materials Membrane Roofs (EPDM, TPO/TFO, PVC, Bitumen & Asphalt Membranes, Gravel / Crushed Stone, Green, Concrete & Timber  Roofs
    Material ZM430 Galvanized Steel, High-Grade Aluminium, Stainless Steel, Plasticizer-Free HDPE, EPDM Rubber
    Coating ZM430 zinc-magnesium-aluminium coating
    Standard colour Black
    Testing/certification European and International Engineering Standards
    Warranty 10 years
    Origin Made in Germany

    Documents for download

    Shipping

    Available for shipping to the UK, Ireland, Africa, the Caribbean and worldwide. If the shipping rate is not shown at checkout, contact us on +44 2080 640335 or info@energian.co.uk for a quote.

    UK expert support

    UK expert support is available for facade-mounting design, wall-fixing suitability and installer referrals. Contact Energian by phone, email or live chat, or visit our office for an in-person consultation.
