- 14kW single phase off-grid inverter for high-demand residential and commercial systems.
- Up to 24kW PV input with dual MPPT and high battery throughput for large storage banks.
- Parallel operation up to 16 units for scalable systems up to well over 100kW.
Overview
The Fogstar x LuxpowerTek SNA 14K Off-Grid Inverter is built for high-demand off-grid and backup systems, combining 14kW AC output with up to 24kW of PV input and 270A battery charge/discharge capability. It is designed to work with 48V lithium-ion and lead-acid batteries and supports flexible configurations for larger homes and commercial applications.
With dual MPPTs, dedicated generator support, fast UPS switching and parallel capability up to 16 units, the SNA 14K provides a powerful and scalable platform for reliable energy supply. It can be used purely off-grid or as part of an “eco hybrid” architecture where solar, generator and grid (where present) can be coordinated to meet site demand.
Key features
- Rated output power 14000W at 230V single phase with sine wave output for sensitive loads.
- Max. PV input power 24000W (12000/12000) with two independent MPPT inputs and wide 100–480V DC input window.
- High battery throughput with 270A max. charge/discharge current at 48/51.2V, suitable for large 48V battery banks.
- UPS switching time <10ms plus overload handling up to 1.5 × rated power for short durations.
- IP20 wall-mount inverter with smart cooling, integrated breakers and remote monitoring via LuxpowerTek app, RS485, Wi‑Fi and CAN.
Typical applications
Ideal for high-demand off-grid homes, large rural properties, workshops, small commercial premises and sites currently running large generators. With suitable Fogstar 48V batteries, it can provide long runtimes for HVAC, refrigeration, IT, lighting and process loads, with generator support where needed.
Recommended Fogstar battery
-
Best overall: Fogstar Energy 48V 32kWh – balanced capacity and performance for most high-demand residential and off-grid systems.
-
Premium option: Fogstar Energy 48V 48.3kWh Modular Battery – maximum storage for extended runtimes and heavy usage in large homes or commercial sites.
-
Scalable option: Fogstar Energy 48V 16.1kWh / 16.1kWh ECO / 10kWh – modular options to start smaller and expand over time as loads grow.
Technical specifications
Quick specs
| Model |
SNA 14K |
| Rated Output Power (W) |
14000 @ 230V |
| Max PV Input Power (W) |
24000 (12000 / 12000) |
| MPPT Inputs |
2 (Dual MPPT) |
| PV Input Voltage Range (V) |
100–480 (max), 120–440 MPPT |
| Rated Battery Voltage (V) |
48/51.2 |
| Battery Type |
Lithium-ion / Lead-acid |
| Max. Charge/Discharge Current (A) |
270A |
| Switching Time (UPS) |
<10ms |
| Rated Output Voltage |
230V (50/60Hz) |
| Waveform |
Sine wave |
| Max. AC Input Power (W) |
24000 |
| Parallel Operation |
Up to 16 units |
| Dimensions (W × H × D) mm |
530 × 830 × 150 |
| Weight (kg) |
43.5 |
| IP Rating |
IP20 |
| Warranty |
3 Years |
PV input (DC)
| Max. PV Input power (W) |
24000 (12000/12000) |
| Rated PV input voltage (V) |
320 |
| Number of independent MPPT inputs |
2 |
| Max. PV input voltage (V) |
480 |
| MPPT voltage range (V) |
120 ~ 440 |
| Start-up voltage (V) |
100 |
| Max. PV input current per MPPT (A) |
35/35 |
| Max. PV short-circuit current input per MPPT (A) |
44/44 |
Battery
| Max. charge/discharge current (A) |
270 |
| Max. charge/discharge power (W) |
13000 |
| Force wake up battery from PV and Grid function |
YES |
Grid / AC input
| Rated AC voltage (V) |
230 |
| AC Start-up Voltage (V) |
90 |
| Acceptable Input Voltage Range (V) |
130 ~ 280 |
| Rated AC frequency (Hz) |
50/60 |
| Rated AC input current (A) |
100 |
| Rated AC input power (W) |
24000 |
| PF |
0.99 |
| THDI |
< 5% |
| Max. continuous AC passthrough current (A) |
100 |
Generator input
| Rated GEN voltage (V) |
230 |
| Rated GEN frequency (Hz) |
50/60 |
| Rated GEN input current (A) |
65 |
| Rated GEN input power (W) |
15000 |
UPS / output
| Rated output power (W) |
14000 @ 230V (with PV + Battery) |
| Rated output voltage (V) |
230 |
| Rated output current (A) |
61 |
| Rated output frequency (Hz) |
50/60 |
| Switching time |
< 10ms |
| Waveform |
Sine wave |
| THDV |
<3 % |
| Overload protection |
5s@≥1.5 × rated power / 10s@(1.1~1.5) × rated power |
Efficiency & protection
| Max. MPPT efficiency |
99.0 % |
| Max. efficiency |
93.5 % |
| Max. Charge/Discharge efficiency |
93.0 % |
| PV reverse polarity protection |
YES |
| Over current / voltage protection |
YES |
| AC Short-circuit current protection |
YES |
| Grid monitoring |
YES |
| DC switch |
YES |
| DC / AC Surge protection |
Type III |
| Battery reverse polarity protection |
YES |
General
| Operating environment temperature range (°C) |
0 ~ 45 |
| Storage temperature range (°C) |
-15 ~ 60 |
| Relative humidity |
5% ~ 95 % |
| Display & Communication interface |
LCD + RGB, RS485 / WIFI / CAN |
| Cooling method |
Smart Cooling |
| Topology on AC / Battery side |
Transformerless / Transformer |
| Max. Operating Altitude (m) |
2000 |
| Noise emission (dB) |
55 |
| Standard & Certification |
IEC 62109-1/-2, EN 62109 / EN 62920 |
Documents available for download
Shipping
Available to the UK, Ireland, Africa, the Caribbean and worldwide. If the shipping rate is not shown at checkout, contact us on +44 2080640335 or info@energian.co.uk for a quote.
UK expert support
UK expert support is available for inverter selection, Fogstar battery pairing, generator integration and full system design. Contact us via phone, email or live chat, or visit our office for an in-person consultation. For most systems we recommend installation by a qualified electrician or one of our trusted installer partners.
