EcoFlow PowerOcean 2 Plus 5.02kWh LFP Battery
- 5.02kWh LiFePO₄ battery module for scalable EcoFlow OCEAN 2 Plus single-phase home energy-storage systems.
- Add storage in modular increments, with systems expandable to 30.12kWh using up to six battery packs on a floor stand.
- IP66 enclosure, integrated safety protections and a compact 279mm battery-pack height for indoor or outdoor installation.
EcoFlow OCEAN 2 Plus 5.02kWh LFP battery storage
The EcoFlow OCEAN 2 Plus 5.02kWh LFP Battery is a modular high-voltage battery pack for compatible EcoFlow OCEAN 2 Plus single-phase hybrid inverter systems. It stores surplus solar energy for use later in the day and can also support tariff-led charging and backup-power configurations when installed as part of a complete system.
Begin with 5.02kWh of nominal storage and expand the battery stack as household demand grows. Up to six battery packs can be installed in a floor-standing stack, reaching 30.12kWh nominal capacity. Wall-mounted configurations support up to three battery packs.
Key features
- 5.02kWh nominal battery capacity per module.
- LiFePO₄ battery chemistry with a 400V / 800V nominal battery voltage architecture.
- 2,500W nominal charging power and 2,500W nominal discharging power for the 5.02kWh configuration.
- IP66 ingress protection for indoor or outdoor installation in a suitable location.
- Floor-standing or wall-mounted installation, with integrated anti-theft support.
Where to use the EcoFlow OCEAN 2 Plus battery
The EcoFlow OCEAN 2 Plus 5.02kWh LFP Battery is intended for homes using a compatible OCEAN 2 Plus single-phase hybrid inverter. It can suit new solar-and-battery installations or systems being designed to expand in stages as electricity demand increases.
Typical applications include storing excess daytime solar generation for evening use, reducing grid import during higher tariff periods, and supporting a professionally designed whole-home or selected-load backup arrangement. Battery capacity should be selected around the property’s solar yield, overnight demand, heating, EV charging and expected future loads.
This battery is not a standalone power source and cannot be used without a compatible inverter and correctly designed system. Installation, commissioning, cable sizing, protection equipment and mounting must be completed by a competent installer. UK expert support is available, and Energian can help arrange installation through trusted partners.
Technical specifications
| Product | EcoFlow OCEAN 2 LFP Battery 5kWh |
| Model | EF BD-5-S2 |
| Battery chemistry | LiFePO₄ |
| Nominal battery capacity | 5.02kWh |
| Nominal voltage | 400V / 800V |
| Operating voltage range | 360–520V / 720–960V |
| Nominal charging power | 2,500W |
| Nominal discharging power | 2,500W |
| Dimensions (W×D×H) | 679.6 × 195.6 × 494.7mm |
| Weight | 54.6kg |
| Installation | Floor stand: up to 6 batteries per stack; wall mounted: up to 3 batteries per stack |
| Operating temperature | -20°C to +55°C* |
| Storage temperature | -25°C to +60°C |
| Maximum operating altitude | 3,000m** |
| Relative humidity | 0%–100% |
| Cooling method | Natural cooling |
| Ingress protection rating | IP66 |
| Anti-theft | Supported |
| Communication method | CAN |
| Certificates | CE Mark |
| Safety standards | IEC/EN 62619, IEC/EN 62040-1, IEC/EN 62477-1, ISO 13849-1, VDE-AR-E 2510-50 |
| Delivery standard | UN 38.3 |
| EMC standards | EN IEC 61000-6-1, EN IEC 61000-6-2, EN IEC 61000-6-3, EN IEC 61000-6-4 |
| Protection functions | Over-charge/over-discharge, over-voltage/under-voltage, over-current, short-circuit, reverse-polarity, temperature, thermal-runaway, leakage-current, insulation, over-pressure, automatic power-off and emergency shutdown protection |
*Power may be derated when the temperature exceeds +40°C.
**Power may be derated above 2,000m altitude.
Documents available for download
- EcoFlow OCEAN 2 Plus 5kWh battery datasheet
- EcoFlow OCEAN 2 Plus 5kWh battery manual
- EcoFlow OCEAN 2 Plus 5kWh battery installation guide
