DMEGC 705W Infinity Mono 132 Cut Bi-Facial N-type Dual Glass Silver Frame Solar Panels
DMEGC 705W Infinity Mono 132 Cut Bi-Facial N-type Dual Glass Silver Frame Solar Panel
- 705 W power and 22.7% efficiency for high-yield ground-mounts and large commercial roofs.
- Bifacial module design, dual 2 mm glass—for added rear gain and extended site life.
- Certified to IEC and MCS; front snow resistance 5400 Pa, rear wind 2400 Pa, salt, ammonia and sand tested.
The DMEGC 705W Infinity Mono Bi-Facial N-type Dual Glass Panel drives premium output and sustained reliability for ground-mount, commercial and utility-scale solar projects. Advanced N-type i-TOPCon cells and robust silver frame resist UK weather and minimise degradation—delivering 87.4% warranted output after 30 years. Extended environmental testing and flexible mounting options make it a trusted choice for yield-critical applications.
Key Features
- 132 half-cut N-type mono cells, i-TOPCon for long-term, high-output and low degradation.
- Dual-glass: 2 mm front/rear, silver anodised frame—proven durability even in exposed UK settings.
- Rated bifacial gain—80 ± 5% (rear), boosting system yields on reflective surfaces and bifacial arrays.
- Low temp coefficient (–0.29%/°C), NMOT 42 ± 2 °C; every module ships at or above rated watts (0–3% tolerance).
- Certifications: IEC 61215/61730/63209/62716/61701/60068, MCS, TÜV Rheinland, WEEE.
- Warranty: 15-year product, 30-year linear power (≤1% first year, ≤0.4% annual, 87.4% at 30 years).
Ideal Applications
Ground-mount solar farms and commercial arrays; large educational, public sector and retail projects. Not DIY—always specify a qualified MCS-accredited installer for compliance and system performance.
Technical specifications
| Module construction | |
|---|---|
| Cell type | N-type mono-crystalline, 132 half-cut, i-TOPCon (6×22) |
| Dimensions | 2384 × 1303 × 33 mm |
| Weight | 37.7 kg |
| Front cover | 2 mm heat-strengthened glass |
| Rear cover | 2 mm heat-strengthened glass |
| Junction box | IP68, 3 diodes, IEC 62790 |
| Connector type | PV-ZH202B or MC4-EVO 2A (1500 V) |
| Performance (STC) | |
| Max power (Pmax) | 705 W |
| Voltage @ Pmax (Vmp) | 40.58 V |
| Current @ Pmax (Imp) | 17.40 A |
| Open circuit voltage (Voc) | 48.62 V |
| Short circuit current (Isc) | 18.48 A |
| Module efficiency | 22.7% |
| Bifacial gain | 80 ± 5% |
| NMOT | 42 ± 2 °C |
| Temp coefficient – Pmax | –0.29%/°C |
| Temp coefficient – Voc | –0.25%/°C |
| Temp coefficient – Isc | +0.048%/°C |
| Operating temp | –40 °C to +85 °C |
| Max system voltage | 1500 V DC (IEC) |
| Overcurrent rating | 35 A |
| Certifications & warranties | |
| Certifications | IEC 61215, IEC 61730, IEC TS 63209, IEC 62716, IEC 61701, IEC TS 63342, IEC 60068, MCS, TÜV Rheinland, WEEE, SolarPower Europe, ISO/SA8000/9001/14001/45001/50001/27001 |
| Product warranty | 15 years |
| Linear power warranty | 30 years (≤1% 1st yr, ≤0.4%/yr, 87.4% after 30 yrs) |
Shipping and expert support
Shipping is available to the UK, Ireland, Africa, the Caribbean and worldwide. If a shipping rate is not shown at checkout, please contact us on +44 2080640335 or info@energian.co.uk for a custom quote.
UK expert support is available – contact Energian with any questions or support requests via phone, email or live chat, or visit our office for in-person consultation.
