Victron Quattro 48/15000/200-100/100 15000VA (12kW) 48V Off-grid Hybrid Inverter Charger

  • Delivers 15kVA continuous power (12kW at 25°C) for heavy industrial loads like site machinery, modular offices, and logistics hubs.
  • Dual AC inputs with 200A adaptive charger support generator + grid priority, ideal for unreliable power sites.
  • Parallel up to 6 units for 90kVA systems; seamless UPS transfer under 20ms keeps critical operations running.

The Victron Quattro 48/15000/200-100/100 combines a robust 15000VA 48V pure sine wave inverter, 200A adaptive battery charger, and high-speed dual AC inputs/transfer switch in one unit. It powers demanding off-grid setups in UK construction sites, remote logistics, and industrial applications with limited space. UK expert installation available via trusted partners – contact us for a quote.

Installation available – contact us for a quote.

Key features

  • 15000VA 48V pure sine wave inverter: Converts DC to 230VAC for heavy appliances (e.g., welders, pumps, HVAC). 12000W continuous at 25°C; 25000W peak for motor starts.
  • Dual AC inputs (200A max charge): Prioritises grid or generator; works with solar controllers and grid-tie inverters for hybrid off-grid systems.
  • Scalable power: Parallel up to 6 units (90kVA/72kW) or three-phase config; suits large sites like warehouses or data centres.
  • 200A 4-stage adaptive charger: Optimises 48V battery charging (bulk, absorption, float, storage) for lead-acid or lithium; temperature-compensated.
  • UPS functionality: <20ms transfer switch prevents downtime for sensitive kit like servers or controls.

Additional intelligent functions

  • Programmable relay: Configurable for generator start/stop or alarms (e.g., low battery, overload).
  • Built-in protections: Against short circuit, overload, over/under voltage, overheating, and input ripple.
  • Remote monitoring: Pairs with Cerbo GX for VRM app/portal access via LAN, Wi-Fi, or internet.

Shipping: Available to UK, Ireland, Africa, Caribbean, and worldwide. FREE 2–3 working days to mainland UK if ordered by 5PM (longer to Highlands/Islands/NI). If no rate at checkout, contact +44 2080640335 or info@energian.co.uk for quote.

UK expert support: Call 020 8064 0335, email info@energian.co.uk, use live chat, or visit our office for consultation.

Detailed Specifications:

Model: Quattro 48/15000/200-100/100
Cont. output power at 25°C: 12000W
Peak power: 25000W
Nominal battery voltage: 48VDC (38-66V)
Output voltage: 230VAC ±2% 50Hz
Max. AC mains current: 100A per input
Max. charge current: 200A
Transfer switch: 100A
Transfer time: 20ms
Inverter efficiency: 96%
Zero load power: 52W; 32W in AES mode
Operating temp: -40 to +65°C (derate above 40°C)
Humidity: 95% non-condensing
IP rating: IP22
Dimensions (H x W x D): 682 x 488 x 344 mm
Weight: 72 kg

In the box:

  • 1 x Victron Quattro 48/15000/200-100/100
  • 1 x Temperature sensor
  • 1 x User manual

Documents available for download:

Warranty: 5-year manufacturer warranty included.
