Key Features
Huge 300Ah Capacity
Provides approximately 3.6kWh of usable energy, ideal for large electrical systems and extended off-grid use.
Integrated Bluetooth Monitoring
Monitor voltage, current, temperature and charge status directly from your smartphone using the built-in Bluetooth connectivity.
Smart Battery Management System (BMS)
The advanced BMS protects the battery from overcharge, over-discharge, overcurrent, temperature extremes and short circuits for safe, reliable operation.
High Energy Discharge
250A Continuous Discharge Current means that a single battery will support a 3000W inverter.
Built-in Low Temperature Heating
The internal heating system automatically warms the cells during charging in cold conditions, allowing safe operation in sub-zero environments.
Long Cycle Life
Engineered for durability with up to 6000 cycles at 80% depth of discharge, delivering many years of dependable service.
High Energy Density Design
Premium prismatic LiFePO4 cells deliver more usable energy while keeping weight and size manageable for vehicle installations.
Market leading 12 year warranty
The warranty covers all parts, not just battery cells
High Quality Prysmatic cells
The battery uses matched Grade A Prysmatic cells for the best reliability and deep discharge
| Specification | Details |
|---|---|
| Battery Chemistry | LiFePO4 (Lithium Iron Phosphate) |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 300Ah |
| Energy | ~3.6kWh |
| Cycle Life | Up to 6000 cycles @ 80% DoD |
| BMS | Smart BMS with full protection |
| Bluetooth | Yes (iOS & Android monitoring) |
| Heating | Integrated internal heating |
| Max Continuous Discharge | 250A |
| Charge Voltage | 14.4V |
| Parallel Connection | Up to 6 batteries |
| Series Connection | Up to 4 batteries |
| Self Discharge | <3% per month |
| Operating Temperature | -20°C to 60°C (with heating) |
Documents for download:
